SML-300 Vertical packaging machine(Suitable for power ,particle,irregular articles)Triangle package

Price: (Standard configuration)
　　Standard Fob Shanghai Port price: *****USD
　　Control system : CPU+stepping motor
　　Interface：touch-tone LCD
　　Spare parts: the present one
　　Attachment: giving code printer
　　Warranty: 1year
　　After sale service: Free training, free installing, free spare parts
　　Payment: TT, 50% for deposit, balance after machine finished.
　　Shipping: Standard sea wooden case
　　Special need: OEM is ok
Note: this price is the unity of the standard configuration of the domestic pricing, declined to bargain.
If you need other configuration, please consult the price to my company business seller

    Features

1.CPU Single chip machine + stepping motor motor control,with convenient and precise setting of the bag length ;
2. Adjusting of the bag length , cursor positioning , coding and other functions can be realized with digital setting ,and they can be input on the operation screen directly.
3. Both Chinese and English language on the operation interface can be switched freely ; Fault self-diagnosis ,and displays on the screen;
4. A variety of packaging forms, a variety of blanking way free combination, suitable for all kinds of packaging items;
5.Bag manufacturing , filling, sealing, cutting,inflation , coding , shutdown with certain quantity and set-cut packaging can be finished automatically.

　Model：SML-300

　Film width：260mm

　Bag length：40-170mm

　Bag width：40-130mm

　Packing speed：30-60bag/min

　Power：220v/2.0kw

　Weight：280KG

　L 720mm

　W 980mm

　H 1680mm

    Photos Related

                    F: tipping bucket feeding

                   S: Turn-plate + tipping bucket feeding

                    J: Turn-plate and counting feeding

                     P: horizontal screw feeding

                   L: vertical screw feeding

                      D: Shaking-plate feeding

                   B: Turn-plate feeding

                                          producing room

    Video Related

mothball packing machine: 4 sides sealing + automatic counting + 5connect bags cutting.

Back sealing packing machine: Back sealing + tipping bucket feeding + coding machine

Wash powder packing machine:  back sealing + measuring cup feeding

Milk tea packing machine: 3 sides sealing + open & close machine feeding

Wash powder packing machine: backing sealing + turn-plate & measuring cup feeding.

    Samples Related

    Knoeledge Related

        SML-300是应用最广，销量最大的立式包装机，用于包装粉末，颗粒，小块物品是非常合适的，机器有多种下料方式，适应不同的包装物. 封口方式有三边封，四边封，背封，三角包等各种封口方式可供您选择， 请参考下图的配置选择，或在 订货的时候，请与我们的技术人员充分沟通，不建议您买贵的机器，只希望你买到合适的机器。
        另外我们还想提醒您，现在网络普及了，大大小小的公司都有个网站，产品介绍也是有模有样的，但是真正的机器质量不敢恭维，您要买设备，还是上门考察吧，眼见为实比较放心。我们诚挚的邀请您来我公司考察和试机，我们免费提供试机的物料，让您买得放心。我们也相信，好的产品经得起考验的！

    Machine Related

类似机型： SML-200袋泡茶包装机 ，SML-260液体/膏体包装机，SML-300立式包装机（适合粉末，颗粒，小块物品） ， SML-380/450大包装立式机（300的放大版本）

    Configuration

    Company introduction

    Shanghai SHUXIN Machinery Co., Ltd main products: Food machines, packing machines, transfer machines and other nonstandard machines. Food machines include: sunflower seed candy equipment, puffed rice candy equipment, peanut candy equipment, sticky candy equipment, nougat equipment, sesame candy equipment,     From the establishing year 2007, our company already has more than thousand customers both here and abroad, more than 3000 sets machines have been sold, with a lot of high opinion.
    Company has develop producing equipment, high level service party, and powerful developing capacity. Now, we have many new technologies which are leading this industry's development, and we have the patents.
Company will focus on products' quality and after sale service more to become a model of mechanical industry.

     The introduction on the web can't fully show our capacity, we sincerely invite you to come to visit and advise our company.
